Description
This has been achieved by exposing the infant to bright light (approximately 4.5 micro watts/sq cm/nm) in the range of 420–480 nm wave length by use of conventional phototherapy unit has been one of SS TECHNOMED’s most important focus in the field of neonatology for many years. In order to remove the limitation of CFL tubes, SS TECHNOMED (P) Ltd. has utilised long lasting, durable, more efficient and cost effective LEDs with more than double the flux as against what is radiated from conventional CFL Tube for jaundice treatment.
Parameter:
- LED 12–18 hi power LEDs (blue) (white LED optional)
- Irradiance >42 mw/cm2/nm at 30 cm
- Light source lifetime minimum 25,000 hrs
- Less than 10% change in illumination after 25,000 hrs (irradiance)
- Wavelength 420–480 nm
- Variation in intensity for 6 hours <10%
- Effective area 50 cm x 30 cm
- Should be specified at the time of order
Electrical:
-
Input voltage 100–240 V, 50–60 Hz
Dimensions: LED box
- Front: (L) 10″ (W) x 3″ (H)
- Backside: 18″ x 8.5″ x 3″
- Height (adjustable):
- Min: 1230 mm
- Max: 1600 mm
- Length: 800 mm
- Width: 720 mm
- Backlit LCD Digital Timer for lamp usage hours and patient exposure
